| Model No. | DMC 585 |
| Optic Diameter | 5.8 mm to 5.0 mm depending on lens power |
| Body Diameter | 6.0 mm |
| Total Diameter | 13.0 mm |
| Haptic Angulation | Mimicking 5° |
| Haptic Micro-Structure | Anti-Sticking Micro-Structure on back side of haptics for model S-Pod LM (Patented Design - OAMI Registration Number 001690975-0001) |
| Slant Haptic Angulation | 10° until Ø 10.0 mm |
| Lens Design | Front Side: Edge Profile to reduce Dysphotopsia Back Side: 360° Square Edge on Optic and Haptic |
| Incision Size | 2.2 mm to 2.6 mm |
| Material | -"Clear" Foldable Hydrophobic Acrylate -"Natural Yellow" Foldable Hydrophobic Acrylate with UV Blocker, -"Yellow Blue-Filter" Foldable Hydrophobic Acrylate with UV Blocker |
| Method of Sterilisation | Gamma, E10 or Plasma Sterilisation in dry stage |
| Diopter range | 10.0D to +30.0D / 0.5 Increment |
| Diffractive zone diameter | Diffractive back optics: +16.0 D to +24.0 D in 0.5 D Inc. Additional power +3.0 D Inc. Additional power +3.5 D Inc. Additional power +4.0 D Inc. Additional power +4.5 D |
| Diffractive pattern on the backside | 3.75 mm |
| Recommended A Constant | Depending on additional power: Add. power +3.0 D 10 rings Add. power +3.5 D 12 rings Add. power +4.0 D 13 rings -Add. power +4.5 D 15 rings |
